Minimizes the effects of wire/cable characteristics, such as shape, diameter, and unevenness, on
measurement accuracy.
Minimizes error arising from slipping during measurement.
Minimizes wear on outer measuring wheel surface over time.
Minimizes curving of wire/cable during measurement.
SPECIFICATIONS
accuracy : better than +0.1% (standard test wire used)
(Please note that margin of error is always positive i.e.1000-1001 ft. for 1000 ft. measured.)
repeatability : better than 0.05% (standard test wire used)
wire/cable diameter range : 20mm - 150mm(0.787 - 5.906 in.)
line speed : up to 80m(app.262 ft.)/min.
air pump : one electric, one manual(only AL-Type)
(Instrument includes both electric and manual air pump to allow easy access in environments with or
without accessible power supply.)
air pressure(raising belt mechanism to allow wire/cable's initial access) : 6psi0.5psi
SPECIFICATIONS
0.5psi
